ALLEGRI AUTOMOTIVE

M 16

CAPACITY 1600 KG

MOBILE ELECTROHYDRAULIC SCISSOR LIFT

TECHNICAL AND MECHANICAL CHARACTERISTICS
The mobile scissor lift M16 is designed to enable free access to all sides of the vehicle so that the operator can easily reach the fixing points of the car battery through the windows. The mobile steel frame oscillates on four heavy duty springs to better adapt to the undercarriage of the vehicle. The frame supports 4 mobile resin-coated plywood planks so that the battery can be safely placed on them to isolate it from electrical charges. The mobile push button block containing the up/down and lock/release controls is always on hand for the operator.

• On request M16 can be supplied with a battery.

    M 16
Max. capacity kg 1600
Lifting time sec 20
Lowering time sec 30
Power supply Volt-A-Hz 230 - 400
Electric motor power Kw- Hp 2,6 - 3,5
Max heigt A mm 1750



ACCESSORIES

Adjustable beam

Universal support kit

Car battery support frame

Wheel support fame

Vehicle accumulator support frame with mobile table
